Exploded View

Fig 1: Exploded View Of Front Coil Spring And Strut With Torque Specifications

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

TORQUE SPECIFICATIONS

(1)	Piston rod lock nut
(2)	Mounting insulator
(3)	Mounting bearing
(4)	Bound bumper
(5)	Upper rubber seat
(6)	Coil spring
(7)	Lower rubber seat
(8)	Strut
(9)	Steering knuckle
	: N.m (kg-m, ft-lb)
	: Always replace after every disassembly .
