Left Side

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

(1)	Circular clip
(2)	Housing
(3)	Snap ring
(4)	Spider assembly
(5)	Stopper ring
(6)	Boot band
(7)	Boot
(8)	Drive shaft
	: Wheel side
	1: Fill repair kit grease.
	2: Apply paste [service parts (MS991241)]
	: Always replace after every disassembly .
