Exploded View

Fig 1: Exploded View Of Parking Brake Control With Torque Specifications

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

(1)	Parking brake actuator harness and rear wheel sensor
(2)	Axle housing
	: Vehicle front
	: N.m (kg-m, ft-lb)
	: N.m (kg-m, in-lb)
