Right Side

WARNING: This page is about a different car, the 2024 Mitsubishi Outlander. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Removing/Installing Front Drive Shaft Components Location With Torque Specification (2WD)

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

(1)	Drive shaft
(2)	Boot band
(3)	Boot
(4)	Stopper ring
(5)	Spider assembly
(6)	Snap ring
(7)	Support bearing bracket
(8)	Housing
(9)	Support bearing
(10)	Dust shield
	: Wheel side
	: N.m (kg-m, ft-lb)
	1: Fill Mitsubishi Genuine grease or equivalent .
	2: Apply paste [service parts (440037S000)] .
	: Always replace after every disassembly .

Fig 1: Removing/Installing Front Drive Shaft Components Location With Torque Specification (AWD)

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

(1)	Drive shaft
(2)	Boot band
(3)	Boot
(4)	Stopper ring
(5)	Spider assembly
(6)	Snap ring
(7)	Support bearing bracket
(8)	Housing
(9)	Support bearing
(10)	Dust shield
	: Wheel side
	: N.m (kg-m, ft-lb)
	1: Fill Mitsubishi Genuine grease or equivalent .
	2: Apply paste [service parts (440037S000)] .
	: Always replace after every disassembly .
