Removal And Installation: Notes

Pre-removal operation	Post-installation operation
Removal of Steering wheel assembly (Refer to STEERING WHEEL .) Removal of Steering column lower cover and steering column upper cover (Refer to STEERING SHAFT .) Removal of Column switch body (Refer to COLUMN SWITCH .) Removal of Instrument panel cover lower (Refer to INSTRUMENT LOWER PANEL .)	Installation of Instrument panel cover lower (Refer to INSTRUMENT LOWER PANEL .) Removal of Column switch body (Refer to COLUMN SWITCH .) Installation of Steering column lower cover and steering column upper cover (Refer to STEERING SHAFT .) Removal of Steering wheel assembly (Refer to STEERING WHEEL .)

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
