Disassembly And Assembly: Notes

Fig 1: Disassembling/Assembling Intermediate Shaft Assembly Components With Torque Specification

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

Required Special Tools:

• MB992209: Bellows Band Clipping Tool
• MB992249: Variable Spanner
