>>C<< Shift Lever Boot Installation

WARNING: This page is about a different variant/trim than selected.
  1. Shift lever boot is hooked and attached to the slot on the control shaft cover.
  2. Install the shift lever boot so that the embossed mark is in the direction shown in the illustration.
G11278186Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
