Power Window Check

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

Check the power window as described below. If it does not work, perform troubleshooting (Refer to SYMPTOM CHART <POWER WINDOW (VEHICLES WITHOUT SAFETY SYSTEM)>  <Vehicles without safety system>, TROUBLE SYMPTOM CHART <POWER WINDOW (VEHICLES WITH SAFETY SYSTEM)>  <Vehicles with safety system>).

• Turn off the power window lock switch of the power window main switch. Operate the front and rear passenger's power window sub switches to check that the power windows work.
• Turn on the power window lock switch of the power window main switch. Operate the front and rear passenger's power window sub switches to check that the power windows do not work.
• Turn on the power window lock switch of the power window main switch, and operate the main switch to check that the driver's power window works but the front and rear passenger's power windows do not work.
