Removal And Installation: Notes

Pre-removal and post-installation operation

• Front Deck Garnish Removal and Installation (Refer to WINDSHIELD WIPER )
• Front Pillar Trim Removal and Installation (Refer to INTERIOR TRIM )
• Inside Rear View Mirror Removal and Installation

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

Required Special Tool:

• MB990480: Glass holder
