Home >> Mitsubishi >> 2017 >> RVR ES, Automatic CVT Trans >> Repair and Diagnosis >> Engine Performance >> Ignition System >> Engine Overhaul (2.0L Engine) >> Balancer Chain (CVT) >> Removal And Installation >> Notes

Removal And Installation: Notes

Fig 1: Removing/Installing Balancer Chain Components With Torque Specifications (CVT)
G10227438Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

Required Special Tool:
