Power Window Operating Current Check

Remove the power window fuse, and connect a multimeter as shown in the illustration.
Raise the power window to measure the current during operation.
Standard value range: 7 A or less [Power supply voltage 14.5 ± 0.5 V, at 25°C (77°F)]

NOTE: If the power supply voltage does not meet the standard value, check and repair the auxiliary battery. Then carry out this check again.

Fig 1: Identifying Power Window Fuse
Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
If the value is outside the standard value, adjust the door window glass (Refer to DOOR WINDOW GLASS ADJUSTMENT ).
