How To Use SWS Monitor

To carry out troubleshooting, operate scan tool MB991958 (M.U.T.-III Sub Assembly) as follows.

Fig 1: SWS Monitor Troubleshooting Flow Chart
G05480228Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
