Home >> Mitsubishi >> 2009 >> Lancer ES, Standard >> Repair and Diagnosis >> Electrical >> Charging Systems >> Charging System >> Generator Assembly >> Removal And Installation (2.0L Engine Turbo) >> Notes

Removal And Installation (2.0L Engine Turbo): Notes

Fig 1: Generator Assembly Replacement Components - 2.0L Engine Turbo With Torque Specifications

G05903644

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
