Module/Frame Assembly - Installation

  1. Install the trough guides. (Refer to GUIDE-TROUGH ASSEMBLY - INSTALLATION )
  2. Install the sight shields.
  3. Install the drive motor. (Refer to CONTROL UNIT - INSTALLATION )
  4. Install the sunshade. (Refer to SUNSHADE - INSTALLATION )
  5. Install the glass panel. (Refer to SUNROOF GLASS - INSTALLATION )
    Fig 1: Removing Backing Tape From Foam Support Pad
    G04286736Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
  6. Remove the backing tape from the foam support pad, if necessary.
  7. Raise rear end of sunroof module assembly and guide into position and start fasteners.
  8. Tighten the fasteners to 9 N. m (80 in. lbs.).
  9. Connect the drain tubes.
  10. Install the wire harness.
  11. Connect battery negative cable.
  12. Test sunroof operation, adjust glass as necessary. (Refer to SUNROOF GLASS - ADJUSTMENTS )
  13. Partially install the headliner and connect the sunroof wiring electrical connectors. (Refer to INSTALLATION )
  14. Temporarily install sunroof switch and perform the sunroof motor teach procedure. (Refer to CONTROL UNIT - STANDARD PROCEDURE - TEACH PROCEDURE )
  15. Complete headliner installation. (Refer to INSTALLATION )
  16. Verify correct sunroof operation.
