Automatic Trans: Cooling: Radiator: Description

Fig 1: Identifying Radiator & Components

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

The radiator (2) is a aluminum cross-flow design with horizontal tubes through the radiator core and vertical plastic side tanks.
