DTC B2212: Occupant Classification Module Internal: Notes
For a complete wiring diagram, refer to SYSTEM WIRING DIAGRAMS .
- When Monitored:
While the IGN status is RUN or signal not available, while the CAN bus system voltage is between 10 and 16 volts, and during the OCS Verification Test .
- Set Condition:
This DTC will set if the module detects an internal failure .
Possible Causes
OCCUPANT CLASSIFICATION MODULE
