Special Tools: Transfer
SPECIAL TOOLS - TRANSFER
| TOOL | TOOL NUMBER AND NAME | SUPERSESSION | APPLICATION |
|---|---|---|---|
| MB990938 Handle | MB990938-01 | Use with installer adapter | |
| MB990932 Installer adapter | - | Installation of oil seal | |
| MB990936 Installer adapter | - | Installation of oil seal | |
| MD998801 Bearing remover | MD998348-01 | Removal and installation of bearing | |
| MD998812 Installer cap | General service tool | Use with installer and installer adapter | |
| MD998826 Installer adapter (52) | General service tool | Installation of transfer input gear bearing | |
| MD998818 Installer adapter (38) | MD998818 | Installation of countershaft gear bearing, front output shaft bearing | |
| MD998368 Bearing Installer | General service tool | Installation of countershaft gear bearing | |
| MD998813 Installer-100 | General service tool | Use with installer cap and installer adapter | |
| MD998814 Installer-200 | MIT304180 | Use with installer cap and installer adapter | |
| MD998917 Bearing remover | General service tool | Removal and installation of bearing | |
| MD998824 Installer adapter (50) | General service tool | Installation of rear output shaft bearing | |
| MD998830 Installer adapter (66) | - | Installation of transfer drive shaft bearing | |
| MD998192 Bearing Puller | General service tool | Installation of transfer drive shaft bearing |
