Operating The Transmitter Unlock Switch Press Once

WARNING: This page is about a different car, the 2005 Mitsubishi Lancer. However, it is still accessible from the selected car via links, so may be relevant.

When the transmitter unlock switch is pressed once, the ETACS-ECU energizes its door unlock relay to operate the door lock actuator of the driver's door for 0.25 seconds thus causing only the driver's door to be unlocked.

Fig 1: Identifying Blinking Pattern (Driver's Door Unlock Function)
G02416394Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
