Removal And Installation: Notes

WARNING:

Before removing the steering wheel, air bag module assembly and clock spring refer to SERVICE PRECAUTIONS and AIR BAG MODULE AND CLOCK SPRING < VEHICLES WITHOUT ADVANCED AIR BAG > or AIR BAG MODULE AND CLOCK SPRING < VEHICLES WITH ADVANCED AIR BAG).
When removing and installing the steering wheel, do not let it bump against the air bag module.

Fig 1: Removing And Installing Steering Wheel With Torque Specifications
Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
