Section 8 (Interior -- Except Evolution)
>>
Front Floor Console Assembly
>>
Removal And Installation
Removal And Installation
WARNING:
This page is about a different variant/trim than selected.
Fig 1: Exploded View Of Front Floor Console Assembly
Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
