Removal And Installation: Notes

WARNING:
  • Never attempt to disassemble or repair the seat belt pre-tensioner. If faulty, replace it.
  • Be extremely careful when handling the seat with pre-tensioner. Do not subject it to shocks, drop it, bring it close to strong magnets or allow contact with water, grease or oil. Always replace it with a new part if any dents, cracks or deformation is found.
  • Do not place anything on top of the seat belt pre-tensioner.
  • Do not expose the seat belt pre-tensioner to temperatures over 90°C (194°F).
  • After operating the seat belt pre-tensioner, replace the seat belt pre-tensioner with a new part.
  • Gloves and protective goggles should be worn when handling a seat belt pre-tensioner once it has been used.
  • If disposing of a seat belt with pre-tensioner which has not yet been used, its seat belt pre-tensioner should be operated first before disposal (Refer to AIR BAG MODULE AND SEAT BELT PRE-TENSIONER DISPOSAL PROCEDURES  .)
Fig 1: Disconnecting Battery Cable From Battery
G02415053Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
