Section 12 (Front Floor Console Assembly - SPORTBACK)
>>
Front Floor Console Assembly
>>
Removal And Installation
Removal And Installation
WARNING:
This page is about a different variant/trim than selected.
Fig 1: Identifying Front Floor Console Assembly Components
Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
