>> H << Select Lever Installation

  1. Apply grease (Mitsubishi Genuine Grease Part No. 0101011 or equivalent) to the control shaft sliding portion of the select lever shoe.
  2. Install the select lever and tighten the bolts to specified torque.
    1. Tightening torque: 18+/-3 N.m (13+/-2 ft-lb)
    Fig 1: Installing Select Cover
    G00977701Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
