Removal And Installation: Notes

WARNING: Before removing the air bag module and steering wheel assembly, refer to AIR BAG SAFETY PRECAUTIONSREMOVAL & INSTALLATION .
Fig 1: Removing And Installation Air Bag Module
G00873343Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
