Sunroof Fit Adjustment

  1. Fully close the roof lid glass.
  2. Fully open the sunshade.
  3. Loosen the screws fixing the roof lid glass assembly, move the roof lid glass assembly along the long hole of the drive cable assembly, adjust the height of the roof lid glass, and check that the space between the roof lid glass and body is consistent along the whole circumference.
  4. After adjusting, check that the sunroof operates smoothly.
Fig 1: Checking Sunroof Timer Function
G01870739Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
