Home >> Mitsubishi >> 2003 >> Lancer ES, Automatic >> Repair and Diagnosis >> Electrical >> Gauges >> Instrument Panel Assembly - Except Evolution >> Instrument Panel Assembly >> Disassembly And Assembly

Disassembly And Assembly

Fig 1: Exploded View Of Front Passenger'S Air Bag Module Components
G01896993Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
