UNDERHOOD Power Distribution Center Identification: Turbo
WARNING:
Always disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician.
- 1 - 30 Amp (Green) Power Window
- 2 - 30 Amp (Green) Engine
- 3 - 40 Amp Headlights
- 4 - 30 Amp (Green) Ignition Switch
- 5 - 30 Amp (Green) Radiator Fan
- 6 - 60 Amp ABS
- 7 - 15 Amp (Blue) Stoplights
- 8 - 15 Amp (Blue) Horn
- 9 - 15 Amp (Blue) Hazard
- 10 - 15 Amp (Blue) Taillights
- 11 - 10 Amp (Red) ABS
- 12 - 15 Amp (Blue) Foglights
- 13 - 10 Amp (Red) Headlamps High-Beam
- 14 - 10 Amp (Red) Air Conditioning
- 15 - 30 Amp (Green) Condenser Fan
- 16 - 10 Amp (Red) Radio
- 17 - 10 Amp (Red) Room Lights
