Fuel Gauge Test: Notes
- Disconnect wiring connector at fuel gauge sending unit inside of luggage compartment. Attach ohmmeter leads between connectorterminals. Resistance should be 7 ohms. If not, remove instrument cluster. Attach ohmmeter leads across fuel gauge terminals on back of instrument cluster and measure gauge resistance. SeeFig 1
.
- Resistance should be 55 ohms. If resistance is low, check for shorted fuel gauge coil. If resistance is high, check for open wire to gauge coil.
Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
