All-round vision camera (Top Rear Side View Camera - TRSVC)
Depending on the options fitted, various camera-based systems are available. Technically, the system is implemented with various cameras and a joint control unit, the TRSVC control unit. TRSVC stands for: Top rear bumper camera. The functions of this camera-based assist system are currently:
- Exterior mirror camera
- Bumper camera
- Rear view camera
NOTE:
Ensure that mandatory connections for optional equipment are in place!
Alongside the already familiar PDC parking and manoeuvring aids and reversing camera, another parking and manoeuvring aid is offered in the form of the bumper camera as well as the exterior mirror camera.
The system is described using the BMW 7-Series as an example.
| Item | Explanation |
|---|---|
| 1 | Rear view camera |
| 2 | Bumper camera |
| 3 | Exterior mirror camera |
