Tire Pressure Monitor (RDC) (Ver. 1): Notes
WARNING: This page does not describe the selected car, but rather 45 other vehicles, including the 2016 BMW M5, 2016 BMW 550i xDrive, 2016 BMW 550i, 2016 BMW 535i xDrive, and 2016 BMW 535i. However, it is still accessible from the selected car via links, so may be relevant.
The Tire Pressure Monitor (RDC) is a system which monitors the tire pressure while the vehicle is in motion. It is offered exclusively in the USA (legal requirement) and as optional equipment (SA2VB).
The system of the new generation (Generation 3) now consists only of 5 components: the RDC control unit (control unit with integrated reception aerial) and 4 sets of wheel electronics.
| Item | Explanation |
|---|---|
| 1 | Wheel electronics system, front left |
| 2 | Wheel electronics system, front right |
| 3 | Wheel electronics system, rear right |
| 4 | Wheel electronics system, rear left |
| 5 | RDC control unit |
