Wiring Diagrams

WARNING: This page does not describe the selected car, but rather 9 other vehicles, including the 2002 BMW Z3, 2002 BMW M Roadster, 2002 BMW M Coupe, 2001 BMW Z3, and 2001 BMW M Roadster. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Manual A/C-Heater System Wiring Diagram (M Coupe & Roadster) (1 Of 2)

Courtesy of BMW OF NORTH AMERICA, INC.

Fig 2: Manual A/C-Heater System Wiring Diagram (M Coupe & Roadster) (2 Of 2)

Courtesy of BMW OF NORTH AMERICA, INC.

Fig 3: Manual A/C-Heater System Wiring Diagram (2000 Z3 - 3.2L)

Fig 4: Manual A/C-Heater System Wiring Diagram (2000-01 Z3 - 2.5L & 2.8L)

Fig 5: Manual A/C -Heater System Wiring Diagram (2002 Z3)

Fig 6: Manual A/C Circuit - (2002 M-Versions)
