Powertrain Control Module (PCM): Removal

All vehicles

NOTE: Powertrain control module (PCM) installation DOES NOT require new keys.

Retrieve the module configuration. Carry out the module configuration retrieval steps of the Programmable Module Installation procedure. For additional information, refer to MODULE CONFIGURATION .

Vehicles equipped with a 4.6L (3V) engine

Remove the air cleaner. For additional information, refer to INTAKE AIR DISTRIBUTION & FILTERING .

All vehicles

Disconnect the RH front wheel speed sensor electrical connector. Remove the nuts and position the A/C tube brackets and wiring harness aside.

Fig 1: Locating Nuts And RH Front Wheel Speed Sensor Electrical Connector
Courtesy of FORD MOTOR CO.
Disconnect the PCM connectors.
Remove the bolts and the PCM.
