Valve Spring, Retainer and Seal: Installation

    NOTE: Lubricate the valve guide with clean engine oil.
    Fig 1: Installing Valve Seal
    G03898350Courtesy of FORD MOTOR CO.
  1. Using the special tool, install the valve seal.
  2. Using the special tool, install the valve spring, retainer and key.
    Fig 2: Installing Valve Spring, Retainer And Key
    G03898348Courtesy of FORD MOTOR CO.
  3. Install the camshaft roller followers. For additional information, refer to CAMSHAFT ROLLER FOLLOWER .
