Valve Cover - RH: Material

ITEM SPECIFICATION

Item Specification
Silicone Gasket and Sealant TA-30 WSE-M4G323-A4
Fig 1: Identifying Valve Cover - RH Components (1 Of 2)
G03990089Courtesy of FORD MOTOR CO.
Fig 2: Identifying Valve Cover - RH Components (2 Of 2)
G03990090Courtesy of FORD MOTOR CO.
