Choke Unloader
- Hold throttle wide open. Using specified drill bit or pin gauge, measure clearance between lower edge of choke plate and air horn wall.
- To adjust, bend metal tang on fast idle speed lever attached to throttle shaft. See Fig 1 . Make sure tang does not touch edge of cam to avoid wide open throttle sticking condition. Rotate throttle lever several times to check for any binding during unloader operation.
