| A0 |
Color code key |
72L |
| A2/18 |
FM 1, AM, CL [ZV] and KEYLESS GO antenna amplifier |
25L |
| A2/71 |
Rear window antenna amplifier 1 |
29L |
| Code 494 |
USA version |
21G |
| Code 494 |
USA version |
21G |
| Code 4U7 |
Start/stop voltage dip protection |
1H |
| Code 551 |
Anti-theft alarm system (ATA [EDW]) |
15G |
| Code B03 |
ECO start/stop function |
1G |
| E19/1 |
Left license plate lamp |
60L |
| E19/1 |
Left license plate lamp |
65L |
| E19/2 |
Right license plate lamp |
61L |
| E19/2 |
Right license plate lamp |
66L |
| E21 |
Center stop lamp |
59L |
| E21 |
Center stop lamp |
64L |
| E21x1 |
Center brake lamp electrical connector |
58J |
| E21x1 |
Center brake lamp electrical connector |
63J |
| E40 |
Trunk lid/liftgate ambient lamp |
40L |
| F32 |
Front electrical prefuse box |
4L |
| F32f158 |
Prefuse 158 |
2K |
| F32f159 |
Prefuse 159 |
6K |
| F32f163 |
Prefuse 163 |
2K |
| F32f164 |
Prefuse 164 |
6K |
| H3/1 |
Alarm siren |
17L |
| K60 |
Coolant circulation pump relay |
22L |
| M14/31 |
Trunk lid/liftgate locking element |
57L |
| M14/7 |
Trunk lid/liftgate central locking motor |
48L |
| M14/7 |
Trunk lid/liftgate central locking motor |
52L |
| M14/7 |
Trunk lid/liftgate central locking motor |
55L |
| M14/7s1 |
Trunk lid/liftgate rotary tumbler switch |
53L |
| M14/7s1 |
Trunk lid/liftgate rotary tumbler switch |
56L |
| M6/4 |
Tailgate wiper motor |
33L |
| N10/2 |
Rear SAM control unit with fuse and relay module |
4A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
12A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
20A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
27A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
36A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
59A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
43A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
51A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
66A |
| N10/2f38 |
Fuse 38 |
31A |
| N10/2f46 |
Fuse 46 |
17A |
| N10/2kE |
Tailgate windshield wiper relay |
33A |
| N26/6 |
Interior protection and tow-away protection control unit |
13L |
| S15/2 |
Liftgate inside door handle |
49L |
| S62/36 |
Trunk lid/liftgate control button |
36L |
| S62/36 |
Trunk lid/liftgate control button |
38L |
| S88/6 |
Trunk lid/liftgate contact switch |
42L |
| S88/8 |
Trunk lid/liftgate external operation switch |
43L |
| S88/8 |
Trunk lid/liftgate external operation switch |
46L |
| U1 |
Valid for USA |
47H |
| U1032 |
Valid for engine 278 and 157 |
20G |
| U12 |
Valid for left-hand drive vehicles |
19J |
| U13 |
Valid for right-hand drive vehicles |
19J |
| U158 |
Valid for folding bench seat in load area |
49G |
| U240 |
Valid for all except ECO start/stop function |
1G |
| U247 |
Valid for trunk lid/liftgate contact switch |
41H |
| U391 |
Valid for gasoline engine 276.8 |
20G |
| U437 |
Valid without code (4U7) Start/stop voltage dip protection |
1G |
| U57 |
Valid for model 218.9 |
27G |
| U57 |
Valid for model 218.9 |
32G |
| U57 |
Valid for model 218.9 |
45G |
| U57 |
Valid for model 218.9 |
54G |
| U57 |
Valid for model 218.9 |
62G |
| U58 |
Valid for model 218.3 |
24G |
| U58 |
Valid for model 218.3 |
37G |
| U58 |
Valid for model 218.3 |
41G |
| U58 |
Valid for model 218.3 |
51G |
| U58 |
Valid for model 218.3 |
58G |
| U657 |
Valid for trunk lid/liftgate control |
37G |
| U880 |
Valid for diesel engine 642 |
7H |
| U89 |
Valid for tilting/sliding roof |
12G |
| U991 |
Valid for all except tilting/sliding roof |
12G |
| W15/2 |
Left footwell ground point |
19L |
| W2 |
Right front ground point at lamp unit |
19L |
| W7 |
Right rear wheel well ground point |
8H |
| W7 |
Right rear wheel well ground point |
42H |
| W7 |
Right rear wheel well ground point |
38G |
| W7/1 |
Right taillamp trunk ground point |
44G |
| W7/1 |
Right taillamp trunk ground point |
59G |
| W7/8 |
Right wheelhouse trunk ground point |
40G |
| W7/8 |
Right wheelhouse trunk ground point |
51G |
| W7/8 |
Right wheelhouse trunk ground point |
61G |
| X8/45 |
Left vehicle interior and trunk lid/liftgate electrical connector |
27J |
| X8/47 |
Left and right trunk lid/liftgate electrical connector |
57J |
| Z6/1z5 |
Circuit 31 connector sleeve |
35H |
| Z6/1z5 |
Circuit 31 connector sleeve |
46H |
| Z6/1z5 |
Circuit 31 connector sleeve |
54G |
| Z6/1z5 |
Circuit 31 connector sleeve |
50G |
| Z6/1z6 |
Circuit 31 connector sleeve |
32G |
| Z6/1z6 |
Circuit 31 connector sleeve |
63H |
| Z6/1z6 |
Circuit 31 connector sleeve |
66H |
