Automatically controlled all-wheel drive (4MATIC), function - GF28.00-P-0001AVC
MODEL 218 with TRANSMISSION 722.961/966/967/971
Automatically-controlled all-wheel drive (4MATIC) in general
The automatically controlled all-wheel drive (4MATIC) is a permanent all-wheel drive with planetary gear differential. Integration of the transfer case in the A/T reduces the teeth engagement and realizes an optimized lubrication concept. The pre-lock torque of 50 Nm serves to improve traction at low engine torque while also helping to avoid any drive train vibrations. The fixed drive torque distribution is 45 % at the front axle and 55 % at the rear axle. The drive torque is distributed via a single-speed transfer case without off-road ratio to the drive axles (drive train).
Further subfunctions are described in:
- 4MATIC transfer case, function
- 4MATIC side output, function
- 4MATIC front axle transmission, function
- Oil supply for 4MATIC transfer case function
- 4MATIC electronic traction system, function
| 4MATIC transfer case, function | GF28.10-P-1000AVC |
| 4MATIC side output, function | GF28.10-P-1010AVC |
| Oil supply for 4MATIC transfer case function | GF28.55-P-3010AVC |
| 4MATIC front axle transmission, function | GF33.10-P-3000AVC |
| 4MATIC electronic traction system, function | GF42.35-P-1000AVC |
| Overview of system components, automatically controlled all-wheel drive (4MATIC) | GF28.00-P-9998AVC |
