TELE AID control unit, location/task/design/function - GF82.95-P-4100RM: Notes

MODEL 230.4 as of 1.7.04 with CODE (359) TELE AID emergency call system with CODE (494) USA version

Fig 1: Identifying Emergency Call System Control Unit
G05076344
  TELE AID control unit, location The emergency call system control unit (N123/4) is located in the center under the rear bench seat
  TELE AID control unit, task   GF82.95-P-4100-02RM
  TELE AID control unit, design The emergency call system control unit (N123/4) is structured as follows:
  • Integral telephone module
  • Integral navigation module
  • Integrated additional battery
  • Memory for vehicle data
  • Screened metal housing

  TELE AID control unit, function   GF82.95-P-4100-04RM
