DTC P0930-71: Shift-Lock Solenoid Circuit Malfunction [Start Stop Unit]: Notes

DTC P0930:71 (START STOP UNIT) DETECTION CONDITION AND POSSIBLE CAUSE

Description	Shift-lock solenoid circuit malfunction
Detection condition	The start stop unit continues to operate the shift-lock solenoid for 30 min or more with the ignition switched ON (engine off or on).
Fail-safe	Inhibits the shift lock control.
Possible cause	DTCs are stored in the TCM. Transaxle range switch circuit malfunction Brake switch connector or terminal malfunction Brake switch (No. 1 signal) malfunction Start stop unit connector or terminal malfunction Short to ground in wiring harness between brake switch terminal D and start stop unit terminal 1C Start stop unit malfunction
Courtesy of MAZDA MOTORS CORP.
