Door Trim Disassembly/Assembly: Notes
WARNING: This page is about a different car, the 2016 Mazda MX-5 Miata. However, it is still accessible from the selected car via links, so may be relevant.
- Disassemble in the order indicated in the table.COMPONENT DESCRIPTION
1 Weather strip 2 Upper frame 3 Recess 4 Armrest 5 Switch panel (See Switch Panel Installation Note .) 6 Center frame 7 Lower frame - Remove the power window main switch when replacing the door trim. (See POWER WINDOW MAIN SWITCH REMOVAL/INSTALLATION .)
- Remove the power window subswitch when replacing the door trim. (See POWER WINDOW SUBSWITCH REMOVAL/INSTALLATION .)
- Assemble in the reverse order of disassembly.
