Troubleshooting Procedure

WARNING: This page is about a different car, the 2016 Mazda CX-3. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Advanced Keyless Entry System Troubleshooting Chart
G10913832Courtesy of MAZDA MOTORS CORP.
