Engine Compartment Side
WARNING: This page is about a different variant/trim than selected.
PART DESCRIPTION
| 1 | EGR valve (See EGR VALVE REMOVAL/INSTALLATION .) (See EGR VALVE INSPECTION .) |
| 2 | EGR pipe No. 2 (See EGR PIPE REMOVAL/INSTALLATION .) |
| 3 | EGR cooler (See EGR COOLER REMOVAL/INSTALLATION .) (See EGR COOLER INSPECTION .) |
| 4 | Purge solenoid valve (See PURGE SOLENOID VALVE REMOVAL/INSTALLATION .) (See PURGE SOLENOID VALVE INSPECTION .) |
| 5 | Catch tank (See PURGE SOLENOID VALVE REMOVAL/INSTALLATION .) (See CATCH TANK INSPECTION .) |
| 6 | Quick release connector (See QUICK RELEASE CONNECTOR (EMISSION SYSTEM) REMOVAL/INSTALLATION .) |
| 7 | EGR pipe No. 1 (See EGR PIPE REMOVAL/INSTALLATION .) |
| 8 | Check valve (intake manifold side) (See CHECK VALVE (EMISSION SYSTEM) REMOVAL/INSTALLATION .) (See CHECK VALVE INSPECTION .) |
| 9 | PCV valve (See POSITIVE CRANKCASE VENTILATION (PCV) VALVE REMOVAL/INSTALLATION .) (See POSITIVE CRANKCASE VENTILATION (PCV) VALVE INSPECTION .) |
