Service Cautions: Reassembly

WARNING: This page is about a different car, the 2018 Mazda CX-9. However, it is still accessible from the selected car via links, so may be relevant.

Standard values, such as torques and certain adjustments, must be strictly observed in the reassembly of all parts.

Fig 1: Reassembling Of Parts
Courtesy of MAZDA MOTORS CORP.

If removed, these parts should be replaced with new ones:

Cotter Pins	Gaskets	Locknuts (Nylon Nuts)	Lock Washers
Oil seals	O-rings	Spring pins	-

Depending on location:
- Sealant and gaskets, or both, should be applied to specified locations. When sealant is applied, parts should be installed before sealant hardens to prevent leakage.
- Oil should be applied to the moving components of parts.
- Specified oil or grease should be applied at the prescribed locations (such as oil seals) before reassembly.

Fig 2: Applying Oil Or Grease At Specified Locations

Courtesy of MAZDA MOTORS CORP.
