Accelerator Pedal Removal/Installation

  1. Disconnect the negative battery cable. (See NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION ).
  2. Remove in the order indicated in the figure below.
    Fig 1: Removing Accelerator Pedal With Torque Specifications
    G11274478Courtesy of MAZDA MOTORS CORP.
    COMPONENT DESCRIPTION

    1 Accelerator pedal
    2 APP sensor connector
  3. Install in the reverse order of removal.
