Troubleshooting Procedure

WARNING: This page is about a different car, the 2016 Mazda CX-5. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Two-Step Deployment Control System Troubleshooting Chart
G10937707Courtesy of MAZDA MOTORS CORP.
