Exhaust side

Fig 1: Engine Related Components With Torque Specification - Exhaust Side
G11437171Courtesy of MAZDA MOTORS CORP.
COMPONENT DESCRIPTION

1 Oil cooler water pipe component (with oil cooler)
(See Oil Cooler Water Pipe Component Installation Note .)
2 Oil filter body
(See Oil Filter Body Installation Note .)
3 Exhaust manifold bracket (2WD)
(See Exhaust Manifold Bracket Installation Note .)
