No. 24 A/C Is Always On Or A/C Compressor Runs Continuously: Notes
NO. 24 A/C IS ALWAYS ON OR A/C COMPRESSOR RUNS CONTINUOUSLY DESCRIPTION AND POSSIBLE CAUSE
| 24 |
A/C IS ALWAYS ON OR A/C COMPRESSOR RUNS CONTINUOUSLY |
| DESCRIPTION |
- A/C compressor magnetic clutch does not disengage.
|
| POSSIBLE CAUSE |
- A/C compressor magnetic clutch engagement is stuck.
- A/C relay is stuck closed.
- Short to power supply in wiring harness between A/C relay and magnetic clutch
- Communication error between instrument cluster and climate control unit
- Communication error between PCM and instrument cluster
- Short to ground in wiring harness between A/C relay and PCM
- PCM malfunction
|
 Courtesy of MAZDA MOTORS CORP.
|
