Mazda
>>
2016
>>
6 Sport, Automatic Trans
>>
Repair and Diagnosis
>>
Restraints
>>
Air Bag, SRS
>>
On-Board Diagnostic - Two-Step Deployment Control System
>>
Foreword
>>
Troubleshooting Procedure
Troubleshooting Procedure
Fig 1: Two-Step Deployment Control System Troubleshooting Procedure Flowchart
Courtesy of MAZDA MOTORS CORP.
Courtesy of MAZDA MOTORS CORP.
