Power System Location Index

Fig 1: Power Systems Related Components

Courtesy of MAZDA MOTORS CORP.

COMPONENT DESCRIPTION

1	Main fuse (See MAIN FUSE REMOVAL/INSTALLATION .)
2	Multiplex slow blow fuse (See MULTIPLEX SLOW BLOW FUSE REMOVAL/INSTALLATION .)
3	Front accessory socket (See FRONT ACCESSORY SOCKET REMOVAL/INSTALLATION .) (See FRONT ACCESSORY SOCKET INSPECTION .)
4	Center accessory socket (See CENTER ACCESSORY SOCKET REMOVAL/INSTALLATION .) (See CENTER ACCESSORY SOCKET INSPECTION .)
5	Fuse block (See FUSE BLOCK REMOVAL/INSTALLATION .)
6	Relay and fuse block (See RELAY AND FUSE BLOCK REMOVAL/INSTALLATION .) (See FUSE SERVICE CAUTIONS .) (See RELAY LOCATION .) (See RELAY INSPECTION .)
7	Front wiring harness protector No.2 (See FRONT WIRING HARNESS PROTECTOR REMOVAL/INSTALLATION .)
8	Front wiring harness protector No.1 (See FRONT WIRING HARNESS PROTECTOR REMOVAL/INSTALLATION .)
