Connectivity Master Unit (CMU) Disassembly/Assembly

  1. Disassemble in the order indicated in the table.
    Fig 1: Connectivity Master Unit Connector And Clips
    G09784159Courtesy of MAZDA MOTORS CORP.
  2. Assemble in the reverse order of disassembly.
